Live Data Stream
Engine speed
Vehicle speed
Coolant temp
88°C
Throttle position
12%
Calculated load
24%
Battery voltage
14.1V
Short fuel trim B1
1.2%
Intake air temp
31°C
RPM and speed history
Diagnostic Trouble Codes
| Code | Description | Status |
|---|---|---|
| P0301 | Cylinder 1 misfire detected | Pending |
| P0420 | Catalyst system efficiency below threshold (Bank 1) | Stored |
| P0171 | System too lean (Bank 1) | Stored |
| C0035 | Left front wheel speed sensor circuit | Active |
| U0100 | Lost communication with ECM/PCM | History |
Freeze Frame (P0301)
| Parameter | Value |
|---|---|
| Engine speed | 2,140 rpm |
| Vehicle speed | 62 km/h |
| Coolant temperature | 91 °C |
| Calculated load | 58 % |
| Fuel system status | Closed loop |
| Odometer at event | 148,302 km |
Vehicle Information
| Field | Value |
|---|---|
| VIN | 1HGCM82633A004352 |
| Vehicle | 2003 Honda Accord 2.4L |
| ECU | Bosch ME7.4.5 |
| Calibration ID | 37820-RAA-A52 |
| Protocol | ISO 15765-4 CAN (11 bit, 500 kbaud) |
| OBD standard | OBD-II (California ARB) |
| Readiness monitors | 7 of 9 complete |
ECU Security Access
Enter the 5-digit technician PIN to unlock extended service functions.
